PARTHAN EP MA SERIES
INDUSTRIAL GEARBOX OILS
Meets specifications:
PARTHAN EP MA meets the FAG FE-8 Test which is now a part of DIN 51517 Part III Specification. PARTHAN EP MA is compatible with most sealants and bearing materials used in industrial applications and recommended for use in heavily loaded step-up spur/ helical/ herringbone/ bevel/ planetary gearboxes in industrial environment.
Product meets DIN 51517 Part III. PARTHAN EP MA Grades are available in ISO VG 150 to ISO VG 460. PARTHAN EP MA Series is available in barrel sizes of 210 Litres.
PARTHAN EP MA in conjunction with HP Lube Solutions™ can lead to improved field service performance.
Special Features
Certain Industrial Gear Units in are exposed to high-load/low-speed conditions which can lead to the breakdown of the lubricating film that is normally required for a long bearing life. This problem was identified by the R&D of Hindustan Petroleum Corporation Limited and premium mineral grade oil PARTHAN EP MA series has been developed to counter the micro-pitting problems.
PARTHAN EP MA has been specially formulated with new generation extreme pressure additive which is chlorine free and offers long term protection against rust and corrosion while simultaneously keeping gear parts clean and also ensuring good filterability. Premium antioxidants provide long service life in applications.
Physico-chemical properties
| PARTHAN | ||||
|---|---|---|---|---|
| EP 150 MA | EP 220 MA | EP 320 MA | EP 460 MA | |
| ISO VG Grade | 150 | 220 | 320 | 460 |
| AGMA Grade | 4 EP | 5 EP | 6 EP | 7 EP |
| Density @ 15°C, g/cc | 0.889 | 0.8900 | 0.8911 | 0.9004 |
| Colour, ASTM D1500 | 2.5 | 3.5 | 4.0 | 4.5 |
| Flash Point, COC, °C | 254 | 264 | 280 | 294 |
| Pour Point, °C | -15 | -9 | -9 | -6 |
| Kinematic Viscosity, cSt, 40°C | 149.9 | 218.8 | 312.8 | 435.3 |
| Kinematic Viscosity, cSt, 100°C | 14.63 | 18.92 | 24.0 | 30.87 |
| Viscosity Index | 96 | 97 | 97 | 101 |
| Total Acid Number, mg KOH/g | 0.68 | 0.68 | 0.71 | 0.69 |
| Cu Strip Corrosion, 3 hrs, 100°C | 1b | 1b | 1b | 1b |
| Four Ball wear scar dia, mm. | 0.27 | 0.27 | 0.26 | 0.26 |
| Four Ball Weld load, kg | 280 | 280 | 280 | 280 |
| FZG Gear test, PLS | >12 | >12 | >12 | >12 |
| Rust Test A&B | Pass | Pass | Pass | Pass |
| Timken OK Load, lb | 70 | 85 | 90 | 90 |
